DDHP-10 to DDHP-500 Deep Drawing Hydraulic Press
High Precision Sheet Metal Forming SolutionParagraph 1 – Overview: The Deep Drawing Hydraulic Press by TAUR SPM is a high-performance machine designed for precision sheet metal forming applications. It is widely used in industries such as automotive, kitchenware, electrical enclosures, HVAC, and aerospace for operations like deep drawing, redrawing, ironing, blanking, and piercing. Paragraph 2 – Performance & Features: This machine offers high accuracy and repeatability with capacities ranging from 10 to 500 tons. It is equipped with a PLC-based control system, HMI touch screen interface, high-efficiency hydraulic power pack, and heavy-duty hydraulic cylinders. The 4-pillar guide structure ensures excellent alignment and stability during operation. Paragraph 3 – Benefits: The press delivers superior surface finish, reduces material wastage, and increases production efficiency. It is built with a robust structure for long service life and requires minimal maintenance. Safety features and easy operation make it a cost-effective and reliable solution for modern manufacturing needs.
For any question or doubt, please feel free to contact us and we look forward to hearing from you!
▼ Function
- 🔹 Features
- Feature Title Description
- High Pressure Forming Enables deep drawing with uniform thickness
- PLC Control System Advanced Siemens-based automation
- HMI Touch Interface User-friendly operation and monitoring
- 4 Pillar Structure Ensures high accuracy and stability
- Hydraulic Power Pack High efficiency and low noise
- Safety Guard System Operator safety with interlock protection
- Easy Maintenance Accessible components for quick servicing
- Custom Die Support Supports customized tooling solutions
- 🔹 Specifications (Specs)
- Label Value
- Capacity 10 to 500 Ton
- Max Pressure 250 Bar
- Daylight Opening 400 – 1000 mm
- Stroke Length 300 – 700 mm
- Bed Size Up to 1500 × 1500 mm
- Slide Size Up to 1400 × 1400 mm
- Speed (Approach) 50 mm/sec
- Speed (Working) 3 – 12 mm/sec
- Speed (Return) 30 – 50 mm/sec
- Motor Power 7.5 HP to 50 HP
- Power Supply 415V AC, 3 Phase, 50Hz
- 🔹 Product Functions
- Deep Drawing Operation
- Redrawing Process
- Ironing Operation
- Sheet Metal Forming
- Blanking Process
- Piercing Operation
- Cup Forming
- Component Shaping
- Thickness Control
- High Precision Manufacturing
