HCS-16 Hydraulic Clamping System
Secure Hold. High Precision. Maximum Productivity.Paragraph 1 (Overview): The TAUR SPM Hydraulic Clamping System is designed to provide secure and precise work holding for industrial applications such as VMC machines, fixtures, SPM, drilling, tapping, and grinding operations. It ensures stable clamping, reduces manual effort, and enhances machining accuracy. Paragraph 2 (Performance): This system delivers high clamping force with hydraulic operation, ensuring consistent performance and leak-proof functionality. It features compact design, easy installation, and supports multiple clamp types such as swing, pull, push, and edge clamps. Operating pressure ranges from 35–70 bar with high efficiency and durability. Paragraph 3 (Benefits): The system improves productivity, reduces vibration, and ensures operator safety. Its long service life, low maintenance requirement, and energy-efficient operation make it a cost-effective solution for modern manufacturing industries.
For any question or doubt, please feel free to contact us and we look forward to hearing from you!
▼ Function
- 🔹 Features
- Feature Title Description
- High Clamping Force Ensures strong and stable work holding
- Leak-Free Performance Designed for zero leakage operation
- Compact Design Space-saving and lightweight structure
- Easy Installation Quick setup with minimal effort
- Long Service Life Durable components with extended lifespan
- Low Maintenance Reduced downtime and servicing cost
- Energy Efficient Optimized hydraulic usage
- 🔹 Specifications (Specs)
- Label Value
- Models Available HCS-16 / 25 / 32 / 40 / 50 / 63
- Clamping Force 4.0 kN to 36.0 kN
- Cylinder Bore 16 mm to 63 mm
- Operating Pressure 35 – 70 Bar
- Max Pressure 100 Bar
- Oil Flow 0.5 – 4.0 LPM
- Clamp Types Swing, Pull, Push, Edge, Power Vice
- Material High Strength Alloy Steel
- Surface Treatment Nitrided / Black Oxide Coated
- Control Hydraulic (Optional PLC Integration)
- 🔹 Product Functions
- Clamping of workpieces
- Fixture holding
- VMC machine operations
- Drilling operations
- Tapping processes
- Grinding applications
- Assembly line clamping
- Automation integration
- Vibration reduction
- Precision positioning
