HCTM-01 Hydraulic Cylinder Testing Machine
High Precision Leakage & Pressure Testing System for Hydraulic CylindersParagraph 1 – Overview: The Hydraulic Cylinder Testing Machine by TAUR SPM is a high-precision system designed for testing hydraulic cylinders, components, and assemblies for leakage, pressure endurance, and performance reliability. It is widely used in manufacturing plants, quality control labs, maintenance workshops, and R&D facilities to ensure product safety and compliance with industry standards. Paragraph 2 – Performance & Features: This machine is equipped with a high-pressure hydraulic power pack, precision pressure gauges, PLC-based control system, and adjustable test fixtures. It supports multiple testing modes including hydrostatic pressure testing, leakage detection, burst testing, and endurance testing. With accuracy up to ±1%, it ensures reliable data recording and repeatable test results. Paragraph 3 – Benefits: The system improves product quality, reduces rejection rates, and enhances safety compliance. It minimizes manual inspection errors and provides automated test reporting for documentation and traceability. Its robust construction ensures long service life, while its user-friendly interface simplifies operation and maintenance.
For any question or doubt, please feel free to contact us and we look forward to hearing from you!
▼ Function
- 🔹 Features
- Feature Title Description
- High Pressure Testing Capable of testing up to 400 bar and above
- Leakage Detection System Accurate identification of micro leakages
- PLC Control System Siemens PLC with HMI touch screen interface
- Adjustable Test Fixtures Suitable for different cylinder sizes
- Data Recording System Automatic test data logging and reporting
- Safety Guard Protection Operator safety with enclosure system
- Digital Pressure Monitoring High accuracy pressure gauge & sensors
- Multi-Stage Testing Supports multiple test cycles and parameters
- Hydraulic Power Pack High performance and stable pressure output
- Easy Operation User-friendly interface with minimal training required
- 🔹 Specifications (Specs)
- Label Value
- Test Pressure Range Up to 400 Bar
- Test Accuracy ±1%
- Flow Rate 5 – 60 LPM
- Cylinder Size Range 500 mm – 3000 mm
- Power Supply 415V AC, 3 Phase, 50Hz
- Motor Power 3 HP – 15 HP
- Control System PLC with HMI
- Operation Mode Manual / Semi-Automatic / Automatic
- Data Recording Yes (Downloadable Reports)
- Safety System Interlock, Guard Protection
- 🔹 Product Functions (one per line)
- Hydrostatic Pressure Testing
- Leakage Testing
- Burst Pressure Testing
- Endurance Testing
- Functional Performance Testing
- Cylinder Quality Inspection
- Pressure Calibration Testing
- Data Recording & Reporting
- Incoming Inspection Testing
- Maintenance & Repair Testing
