HDL-6 Hydraulic Dock Leveler
Safe • Strong • Reliable – Smart Solution for Warehouse Loading & UnloadingParagraph 1 (Overview): The TAUR SPM Hydraulic Dock Leveler is a high-performance solution designed for efficient loading and unloading operations in warehouses, logistics hubs, and industrial facilities. It bridges the gap between the dock and vehicle, ensuring smooth and safe material handling. Paragraph 2 (Performance): This dock leveler offers a load capacity ranging from 6 to 20 tons and operates using a robust hydraulic system. It features smooth up-and-down movement, automatic lip extension, and stable platform support. Built with heavy-duty steel construction, it ensures durability and consistent performance under demanding conditions. Paragraph 3 (Benefits): The system significantly reduces manual effort, improves safety, and enhances operational efficiency. With low maintenance requirements, long service life, and high reliability, it provides a cost-effective and time-saving solution for industrial loading operations.
For any question or doubt, please feel free to contact us and we look forward to hearing from you!
▼ Function
- 🔹 Features
- Feature Title Description
- High Load Capacity Handles 6 to 20 tons भार सहज उचलतो
- Smooth Operation Hydraulic system ensures jerk-free movement
- Strong Steel Construction Heavy-duty platform for long durability
- Safety Toe Guard Protects operator during operation
- Anti-Slip Platform Ensures safe loading even in wet conditions
- Easy Installation Quick setup with minimal civil work
- Low Maintenance Requires minimal servicing
- Hydraulic Power System Efficient and reliable power operation
- 🔹 Specifications (Specs)
- Label Value
- Models Available HDL-6 / HDL-10 / HDL-15 / HDL-20
- Load Capacity 6 Ton / 10 Ton / 15 Ton / 20 Ton
- Platform Size 2000×2000 mm to 2200×3000 mm
- Lip Length 400 – 500 mm
- Working Range +300 mm / -300 mm
- Motor Power 1.5 HP – 3 HP
- Power Supply 415V AC, 3 Phase, 50Hz
- Operation Push Button / Remote / PLC (Optional)
- Material Heavy Duty Steel
- Finish Anti-corrosion / Painted / Galvanized (Optional)
- 🔹 Product Functions
- Bridges dock and truck height gap
- Enables smooth loading and unloading
- Supports heavy load transfer
- Improves warehouse efficiency
- Reduces manual labor
- Enhances operator safety
- Prevents goods damage
- Allows fast truck turnaround
- Ensures stable platform positioning
- Supports automated logistics systems
