IMAHU-05 / 10 / 20 / 30 Injection Molding Auxiliary Hydraulic Unit
Paragraph 1: The TAUR SPM Injection Molding Auxiliary Hydraulic Unit is designed to provide reliable hydraulic power for plastic injection molding machines and related industrial applications. It supports operations such as clamping, injection, mold opening/closing, and core pulling, making it essential for plastic processing industries. Paragraph 2: This unit is equipped with high-performance components including an electric motor, hydraulic pump, solenoid valves, and precision control systems. It offers stable pressure and flow with a range up to 160 bar and flow rates up to 100 LPM. Available in air-cooled or water-cooled configurations, it ensures smooth, energy-efficient, and low-noise operation. Paragraph 3: Built with a compact and durable design, the system ensures long service life with minimal maintenance. It enhances productivity, reduces energy consumption, and provides flexible customization options. The unit is easy to install and operate, making it suitable for modern automated manufacturing setups.
For any question or doubt, please feel free to contact us and we look forward to hearing from you!
▼ Function
- 🔹 Features
- Feature Title Description
- High Pressure Capability Supports up to 160 bar operation
- Energy Efficient Design Optimized for low power consumption
- Compact Structure Space-saving design for industrial setups
- Smooth Operation Low noise and vibration-free performance
- High Quality Components Ensures durability and reliability
- Overload Protection Protects system from damage
- Easy Maintenance User-friendly service access
- Custom Design Configurable as per requirement
- 🔹 Specifications (Specs)
- Label Value
- Motor Power 5 HP – 30 HP
- Flow Rate 20 – 100 LPM
- Max Pressure Up to 160 Bar
- Oil Tank Capacity 60 – 200 Liters
- Cooling System Air Cooled / Water Cooled
- Control System Manual / Electrical / PLC (Optional)
- Power Supply 415V AC, 3 Phase, 50Hz
- Pressure Range Low: 0–30 Bar / Medium: 30–100 Bar / High: 100–160 Bar
- 🔹 Product Functions (one per line)
- Clamping Unit Operation
- Injection System Support
- Mold Open / Close Control
- Ejection System Operation
- Core Pull System
- Hydraulic Cylinder Control
- Pressure Regulation
- Cooling System Support
- Accumulator Charging
- Auxiliary Power Supply
